Congratulations and thank you for exploring the SYN series Audio amplifiers, the logical choice in mobile audio amplification. Your amplifiers have been designed and engineered with the highest quality components and top of the line workmanship to help you reach the superior sound you are after.
Amplifier secs:
RMS power @ 4 ohm 2100 W X 1
RMS power @ 2 ohm 3800 W X 1
RMS power @ 1 ohm 6500 W X 1
RMS power @ 4 ohm mono -
Amplifier Type Class D
Minimum load impedance 1 ohm stable
Input Sensitivity 0.2 V - 6 V
High Pass Filter
Low Pass Filter
35 Hz - 250 Hz
Subsonic Filte 10 Hz - 50 Hz
Bass Boost
Frequency Response
10 Hz - 250 Hz
Signal to Noise Ratio 85 dB
THD@4ohm <0.1%
Damping Factor >200
Working voltage 9 V - 16 V
Fuse Rating 200A x 3
Dimensions ( inches ) 26.77 L x 9.45 W x 2.44 H inches
