Rockford Fosgate PMX-1 Punch Marine Grade Media Receiver with 2.3" Dot Matrix Display

The PMX-1 features a 9H tempered glass screen optically bonded which allows for optimized viewing of the dot matrix display under all lighting and viewing conditions. The superior Bluetooth® audio features A2DP and AVRCP for better range, easier device pairing and glitch free wireless audio streaming. The flexible AUX and USB inputs enable convenient access to various audio playback formats and charging of your mobile devices.

FEATURES AT A GLANCE

• Wet bonded 2.3" Full Dot Matrix LCD Display
• Compatible with PMX-BTUR Steering Wheel Remote
• Independent Subwoofer Level Control
• 9H Tempered Glass Screen
• A2DP and AVRCP Bluetooth® Wireless Streaming
• FCC, CE and EN60945 Certified
• Multi-region radio frequencies
• IP6 Marine Grade Front Panel
• Voltage gauge with Low voltage Warning
• AM/FM/WB Tuner
• Selectable HP / LP / AP Crossovers with Selectable Slope 12 / 24 dB/Oct
• AUX and USB Inputs with USB Charging
• 2-Year Warranty
• 7-Band Graphic EQ + PEQ

Multi-Zone/Multi-Source
(Yes/No)

No

Device Type

Digital-Media Receiver

Speaker Outputs
(Yes/No)

Yes

Pandora® Internet Radio
(Yes/No)

No

Steering Wheel Control Ready
(Yes/No)

No

AUX Input
(Yes/No)

Yes (1 RCA pair)

SiriusXM-Ready®
(Yes/No)

No

Clock
(Yes/No)

No

Bluetooth®
(Yes/No)

Yes
3.0+EDR, A2DP 1.3

USB Charging
(Yes/No)

Yes

AM Tuner

Range: 530 - 1710 kHz
Sensitivity: 40 dB
Frequency Response: 45 to 2.4 KHz

TUNER
Number Of Presets

18 FM / 12 AM / 6 WB

Frequency Response

RCA: 20 Hz - 20 kHz
High-Level: 20 Hz - 20 kHz

Power Output (max)

CEA-2006 Power Rating
25W x 4 @ 4Ω RMS
50W x 4 @ 2Ω MAX
≤1.0% THD+N

FM Tuner

Range: 87.9 - 107.9 MHz
Sensitivity: 8 dB
Frequency Response. 20 - 15 KHz
