DS18 DSP2.6DBT 2-Channel In and 6-Channel Out Digital Sound Processor with Bluetooth and LCD Screen

DS18 DSP2.6DBT 2-Channel In and 6-Channel Out Digital Sound Processor with Bluetooth and LCD Screen

Regular price $169.99
Regular price $189.99 Sale price $169.99
Sale Sold out
Shipping calculated at checkout.

DS18 DSP2.6DBT


2-Channel In and 6-Channel Out Digital Sound Processor with Bluetooth and LCD Screen

DS18 proudly presents the DSP2.6DBT: a 2-channel in and 6-channel out digital sound processor designed to revolutionize your car audio experience.
At DS18, we understand that true audiophiles seek control – absolute dominion over every aspect of their soundstage. The DSP2.6DBT is your key to unlocking that control, putting the immense power of your audio system at your fingertips.
Creating the perfect audio system has never been easier, thanks to the DSP2.6DBT's intuitive features. Our BT Interface grants you direct access to an extensive list of filtration settings, ensuring that your sound is tailored precisely to your preferences. Our dedicated DSP2.6DBT Application, available on both the App Store and Google Play, dares you to fine-tune and monitor every aspect of your signal processing. Effortlessly save presets for specific songs or genres, creating the ideal listening experience every time.
The DS18 DSP2.6DBT takes audio tuning to an entirely new level with its Precision Parametric Equalizer. This advanced feature grants you the power to sculpt your sound with surgical precision. With 3 independent bands per channel, you have unparalleled control over the frequencies, allowing you to fine-tune every aspect of your audio reproduction.
The DS18 DSP2.6DBT introduces you to a world of limitless sonic possibilities with its Dynamic Crossover Filters. Featuring Butterworth, Linkwitz-Riley, and Bessel filters, this exceptional digital sound processor allows you to tailor the audio spectrum with unparalleled accuracy. Prepare to be immersed in a world of sonic bliss, where every note is precisely crafted, and every detail is faithfully reproduced.

SPECS

Type
Unbalanced
Connection
RCA
Max level
Up to 6 Volts RMS
Impedance
47kΩ


OUTPUTS (1,2,3,4,5,6,7,8)

Type
Unbalanced
Connection
RCA
Max Level
2 Volts RMS
Impedance
470k Ω


TECHNICAL INFORMATION

Resolution
24 Bits
Sample Frequency
48KHz
Latency Frequency
1.08ms
Range Frequency
15Hz a 22KHz (-1db)
THD+N max
0.01%
Signal Noise Ratio
100dB


POWER SUPPLY

Voltage
10~15Vdc
Consumption
300mA (5w)
Fuse
2A


DIMENSIONS

Dimensions (H x L x D)
1.18" x 9.84" x 4.72" / 30 x 250 x 120mm
Weight
382g / 13.4 Oz


SHIPPING INFO

Dimensions L x W x H (Inches)
10 x 5.25 x 1.5
Weight (lb)
1
M/C Dimension L x W x H (Inches)
21.25 x 13.75 x 11
M/C Weight (lb)
31
M/C Qty
30 Pcs
