DS18
DS18 8PRO300MB-8 8" Mid-Bass Loudspeaker 300 Watts 8-Ohm
DS18 8PRO300MB-8 8" Mid-Bass Loudspeaker 300 Watts 8-Ohm
DS18 8PRO300MB-8
PRO 8" Mid-Bass Loudspeaker 300 Watts 8-Ohm
Immerse yourself in a world of crisp, powerful sound with the DS18 8PRO300MB-8 speakers! Professional Audio speakers should be engineered to slay their respective frequency ranges, and when it comes to the mid-bass range, the 8PRO300MB-8 reigns supreme!
Featuring a design that prioritizes powerful and punchy bass responses, the 8PRO300MB-8 is capable of delivering crystal-clear sound without any distortion, making it an ideal choice for anyone who likes their music loud and proud!
One of the standout features of these speakers is their impressive frequency response range, which spans from 60Hz to 5KHz. This means that you can expect a solid mid-bass response from the 8PRO300MB-8, essential for reproducing the lower frequencies of your music with crystal-clear clarity and impactful bass notes that truly resonate.
Boasting a 8 ohm impedance, the 8PRO300MB-8 reduces overall power consumption and heat generated by your system. In addition to the 8-ohm configuration, the 8PRO300MB 6.5" Mid-Bass Loudspeaker is also available in a 4-ohm configuration.
With a 1.5” voice coil that can handle 150W RMS and 300W Max power levels, these speakers provide an impressively manageable power setting for a speaker with an incredibly high 96 dB sensitivity!
If you're on the hunt for a professional audio speaker that can play mid-bass notes with authority, then look no further than the DS18 8PRO300MB-8!
SPECS
SKU
8PRO300MB-8
Nominal Diameter
8" / 203mm
Nominal Impedance
8 Ohm
RMS Power Handling
150W
Maximum Power Handling
300W
Sensitivity (1w/1m)
97 dB
Frequency Response
60Hz-5KHz
Recommended HI Pass Crossover
80Hz
Sold in Pair or Single
Single
Grill Included
No
MOTOR
Voice Coil Diameter
1.5" / 38.1mm
Voice Coil Former Material
Kapton
Winding Material
CCAW
Cone Material
Paper
Dust Cap Material
Paper
Surround Material
Cloth
Basket Material
Steel
Basket Color/Finish
Satin Black
Magnet Material
Ferrite
Magnet Weight
20oz
Displacement Volume
0.48L / 0.016ft3
THIELE & SMALL PARAMETERS
Equivalent Volume Vas
18.18L / 0.64ft3
Excursion (one way) Xmax
9.8mm
Free Air Resonance Fs
80Hz
Mechanical Factor Qms
1.92
Electrical Factor Qes
0.53
Total Factor Qts
0.42
Moving Mass Mms
13.78g
Compliance Cms
0.28mm/N
Bl Factor Bl
8.74
Voice Coil Inductance Le
0.19mH
Diaphragm Area Sd
213.82cm2
DC Resistance Re
5.8ohms
MEASUREMENTS
Overall Diameter
8.2" / 210mm
Overall Depth
3.8" / 98mm
Front Mount Baffle Cutout
7" / 178mm
Mounting Depth
3.6" / 92mm
Motor Diameter
4.5" / 115mm
Gross Single Unit Weight (lb)
5.5
Dimensions W x L x H (Inches)
9 x 9 x 4.25
Quantity of Units in Master Carton
8
Gross Master Carton Weight (lb)
44
M/C Dimensions W x L x H (Inches)
18.25 x 18.25 x 9.25
